Inside Gryt's Infrastructure

The big picture

Gryt is a set of independent services. Each handles one concern — signaling, media, identity, storage, persistence — and they talk over well-defined boundaries. Every service runs in its own container, every connection is authenticated, and every piece of the stack can be self-hosted.

Here's the full picture:

Every arrow in that diagram is deliberate. Let me walk through each component and explain why it exists, how it works, and what security properties it provides.

Services and what they do

Client, the user-facing layer

The Gryt client is a React app that ships two ways: as a web app served by Nginx in Docker, and as an Electron desktop app with auto-updates. The client handles the UI, audio capture, noise suppression (via RNNoise), and the WebRTC peer connection to the SFU.

Critically, the client holds no secrets. Authentication uses OIDC with PKCE, a public client flow where no client secret is needed. The client redirects you to the Keycloak instance at auth.gryt.chat, you authenticate there, and the client receives a short-lived token. It never sees or stores your password.

Server, signaling and coordination

The signaling server is a Node.js app using Socket.IO for real-time WebSocket communication and Express for REST endpoints. It's the brain of a Gryt server: it manages rooms, user presence, chat messages, file uploads, and coordinates the WebRTC handshake between clients and the SFU.

Each server instance gets its own ScyllaDB keyspace, providing full data isolation when you run multiple servers. The server also connects to MinIO for S3-compatible file storage (avatars, attachments, custom emoji).

When auth is enabled, the server validates identity tokens against the Keycloak JWKS endpoint on every connection. It also issues its own short-lived JWTs (signed with JWT_SECRET) for subsequent API requests, and those tokens are scoped to a specific server host and carry a version number that can be invalidated server-wide.

SFU, media routing

The SFU (Selective Forwarding Unit) is written in Go using the Pion WebRTC library. Its job is simple: receive one audio stream from each participant and forward it to everyone else in the room. No mixing, no transcoding, no decryption.

Each client uploads a single audio stream regardless of room size. The SFU does the fan-out. This keeps bandwidth constant for every participant, whether there are 2 people or 20.

The SFU communicates with the signaling server over an internal WebSocket for room management and credential validation. It exposes a UDP port range for WebRTC media, which is the only thing that needs to be publicly accessible.

Auth, Keycloak

Gryt uses Keycloak as its identity provider, hosted at auth.gryt.chat. Keycloak is a battle-tested, open-source OIDC/OAuth 2.0 server used in enterprise environments by Red Hat, the German government, and thousands of other organizations.

You are not expected to host Keycloak yourself. The auth package, including the realm configuration, custom theme, and Docker setup, is published in the repo purely for transparency. You can see exactly how the instance is configured, what data it stores, and how the login theme works. It's open so you don't have to take my word for it.

When you log in to Gryt, here's what actually happens:

The important thing to notice: the signaling server never sees your password. It only receives a signed JWT from Keycloak and verifies the signature against Keycloak's public keys (the JWKS endpoint). The server doesn't even need to talk to Keycloak at auth time. It just needs access to the public key set, which it caches.

Database, ScyllaDB

Gryt uses ScyllaDB, a high-performance NoSQL database compatible with the Cassandra query language (CQL). It stores server configuration, user profiles, chat messages, roles, and member data.

Each server instance operates in its own keyspace, meaning you can run multiple independent Gryt servers from a single ScyllaDB cluster with full data isolation.

Object storage, MinIO

File uploads (avatars, attachments, custom emoji) are stored in MinIO, an S3-compatible object storage server. This keeps binary data out of the database and makes it easy to swap in any S3-compatible backend: AWS S3, Backblaze B2, Cloudflare R2, or your own MinIO cluster.

How auth works, and what you're trusting

This is the part I care about most, because it's the part most platforms get wrong.

With Discord, Slack, Teams, or any other centralized platform, your identity is owned by that company. Your username, your email, your profile, your social graph, your login history: all stored on their servers, governed by their policies, accessible to their employees, and deletable at their discretion.

Gryt is different, but I want to be honest about what it is and isn't.

By default, Gryt uses a hosted Keycloak instance at auth.gryt.chat, run by me. When you sign up, your email and password go to that Keycloak instance. That means you're trusting me with those credentials. That's it. I don't want to oversell this.

What I can tell you:

• Server hosts never see your password. The signaling server only receives a signed JWT and verifies the signature against Keycloak's public keys. It doesn't talk to Keycloak at auth time; it just needs the JWKS endpoint. Your password stays between you and the Keycloak instance.
• One identity, every server. You sign up once and your identity works across every Gryt server. Server hosts validate your token cryptographically. They don't store or manage your credentials.
• You can use a throwaway email. The only requirement is that your email address can receive a verification link. If you don't want to hand over your real one, use a one-time obfuscated address. Keycloak doesn't care, and neither does Gryt.
• The auth source is open. The auth package is open source for transparency, so you can audit exactly what's running at auth.gryt.chat.
• No data sharing. No tracking. Period. Gryt shares no data with third parties, not from Keycloak, not from the signaling server, not from anywhere. There is no analytics, no telemetry, no usage tracking of any kind. Nothing phones home. Your data exists in exactly one place: the infrastructure that runs it.

If you want to go further, self-hosting Keycloak is technically possible. The code and theme are all in the repo. But it's not expected, and full self-hosted auth documentation is still planned. The default setup points every server at auth.gryt.chat because centralized identity is what makes "sign up once, join any server" work.

The architecture still gives you meaningful separation: the people running the servers you join never see your credentials. They get a cryptographically verified identity and nothing else.

How the security model works

Security in Gryt follows from how the services are structured, rather than being bolted on at the end. Here's a summary of the layers:

Media encryption (DTLS-SRTP)

All voice data is encrypted using DTLS-SRTP, which is mandatory in WebRTC. The encryption is negotiated directly between the client and the SFU:

1. The client and SFU establish a UDP path via ICE
2. A DTLS handshake runs over that path to exchange encryption keys
3. All subsequent audio packets are SRTP-encrypted

The SFU forwards encrypted packets without decrypting them. It can route audio but can't listen to it. That is a property of the architecture, not a policy I am asking you to believe.

Token-based authentication

When auth is enabled, every connection goes through two layers of token verification:

1. Identity verification. The client presents a Keycloak-issued JWT. The server verifies the signature against the JWKS public keys, checks the issuer, audience, and expiry.
2. Session tokens. After identity verification, the server issues its own short-lived JWT, scoped to the specific server host. These carry a tokenVersion that can be invalidated server-wide if needed (for example, after a security incident).

Authorization: Bearer <server-issued JWT>
├── serverHost: "api.gryt.example.com"  ← scoped to this server
├── tokenVersion: 3                     ← stale tokens are rejected
└── sub: "user-uuid"                    ← identity from Keycloak

If a token's serverHost doesn't match the current server, it's rejected. If the tokenVersion is behind the server's current version, it's rejected. Both of these are checked on every authenticated request.

Network isolation

In the default Docker Compose deployment, services communicate over an internal bridge network. The only ports exposed to the outside are:

Port	Service	Protocol	Purpose
3666	Client	TCP	Web UI
5000	Server	TCP	API + WebSocket
5005	SFU	TCP	Signaling
10000–10019	SFU	UDP	WebRTC media

ScyllaDB and MinIO are never exposed to the public network. They only accept connections from within the Docker network. The SFU's internal WebSocket (used by the signaling server for room management) also stays internal.

For Cloudflare Tunnel deployments, HTTP services bind to 127.0.0.1, so they're not reachable from the network at all, only through the tunnel. The UDP ports for WebRTC are the only exception, since Cloudflare Tunnel doesn't support UDP.

No implicit trust between services

The SFU doesn't blindly accept connections. When a server registers a room with the SFU, it provides credentials. When a client tries to join, the SFU validates those credentials before creating a peer connection. If the signaling server goes down, the SFU cleans up empty rooms after a timeout rather than leaving zombie sessions.

Deployment flexibility

One of the design goals is that you should be able to run Gryt anywhere, with whatever infrastructure you're comfortable with. The stack supports:

• Docker Compose: one command, runs everything on one machine
• Cloudflare Tunnel: zero-config TLS, no open ports (except SFU UDP)
• A reverse proxy: Caddy, Nginx, or Traefik with automatic TLS
• Kubernetes: Helm chart with ingress, security contexts, and resource limits

The entire stack runs with a single docker compose up -d. No build step, no compilation, no dependency installation. Pre-built images are published to GHCR on every release.

What this means in practice

When you host a Gryt server:

• Your voice data is encrypted between your browser and the SFU, and the SFU can't decrypt it
• Your messages and files are stored in your own ScyllaDB and MinIO, on your own disks
• Your identity is verified cryptographically, so server hosts never see your password or manage your credentials
• No telemetry, no analytics, no data sharing. Nothing leaves your server except auth token validation against auth.gryt.chat
• The entire stack is open source under AGPL-3.0, so you can audit every line

The trust you're placing is narrow and explicit: you trust the hosted Keycloak at auth.gryt.chat with your login credentials, and you can use a throwaway email if you prefer. Your voice, your messages and your files live on infrastructure you control.

That's the goal. Minimal trust, with the lines drawn where you can see them.

---

If you want to set up your own instance, check the deployment guide. If you want to dig into the source, everything is on GitHub. Questions? Come chat on our Gryt server or Discord.
